By Christopher Brown of OCDCarCare.com
Vehicle water spots, also called hard water spots or mineral deposits, are the annoying white marks or rings found on many automotive surfaces worldwide.
The truth is vehicle water spots are a common paint and surface defect which carry a high potential to damage automotive surfaces. The damage potential of water spots to automotive surfaces, is mostly based on the amount of minerals or harmful chemicals contained within water when it evaporates from a vehicle’s surface. This can radically change based on the water source, making water spots a potential reality whenever water dries on a vehicle surface.
This article deeply examines automotive water spots in order to provide information for everyone from vehicle owners to professional auto detailers to provide detailed information about:
- water spot creation/formation
- minerals: defining ‘hard’ or ‘soft’ water and how it directly contributes to vehicle water spotting
- a water spot’s potential to damage surfaces
- water spot prevention tips
- water spot removal methods
- a ceramic or ‘graphene’ coating’s water spot protection capabilities
How Vehicle Water Spots Form: A Scientific Overview & Explanation
Automotive water spots form when water dries on a surface. As the water evaporates, hard mineral deposits and contamination are left behind on the surface. Seems simple enough—but there’s a bit more to it.
It’s unfortunate, but if a vehicle remains stationary, and water partially or fully dries on the surface, nothing can be done to prevent water spots. Minerals and contamination, if left on a vehicle surface, have a good chance to form by penetrating into porous automotive surfaces such as: paint, glass, sensitive plastics, gel coat, and some exposed metal surfaces.
Automotive water spotting most frequently occurs when a car, truck, boat, or RV’s surfaces are hot before water contact, or when the surface heats with water already sitting on a surface. If a vehicle surface temperature is cool or cold during water contact, then water spotting may not occur. However, if vehicle surfaces are HOT at the time of water contact, the likelihood of water spot creation increases dramatically– almost exponentially.
Automotive paint, at any temperature, always carries the potential for minerals to seep DEEP into its porous structure to create ugly or damaging water spots. Often times, heavy concentration of minerals or other contaminants can penetrate so far into a vehicle’s paint system that they form at or below fully cured ceramic coatings.
This occurs because automotive paint is engineered as a thermally dynamic structure. A mean feature of vehicle paint, enabling it to deal with large doses of heat, is its porous structure. Therefore, when a vehicle’s paint surface is HOT, 140°F (60° C) and often much higher, it’s porous structure swells wide open, allowing maximum vulnerability.
When water contacts a hot panel, the water evaporates quickly, if not instantly. Rapid water evaporation leaves behind the minerals and other potential chemical contamination, previously contained within the water, to embed themselves and chemically attach deep inside the paint’s structure.
The damage to automotive surfaces from hard water spots may vary on a wide scale. The concentration of water spot minerals or contamination may be light, moderate, heavy, or extreme.
Any damage, caused by automotive water spots, completely depends on: the type of minerals, their concentration levels, along with any other chemical agents present within the water, or on the surface, at time of water contact. Additionally, the hotter the surface at the time of full evaporation, the higher the likelihood of deeper or more damaging water spots on a vehicle surface.
Some common minerals contained within water, such as calcium and magnesium, are extremely alkaline. A high concentration of calcium may cause etching to some paint systems. Etching or etch marks are the condition where the contaminants within the water have damaged the paint which looks and or feels like a crater. Essentially the contamination has eaten away at the surface and created a recessed area in the shape of the water spot.
Similar to water spot formation, the severity of a vehicle’s water spot etching depends on a combination of factors, including the chemical resistance capability of a vehicle paint or surface, the type of minerals and or contamination present at formation, the overall concentration levels of these minerals or contaminants, and the length of time those corrosive agents interacted with the paint.
The Dangers of Hard Water Spots (Mineral Deposits) to Vehicle Surfaces
Sure, water spots cause ugly white blemishes on automotive finishes, particularly on darker colored vehicles. However, the potential for chemical damage caused by vehicle water spots are of far greater concern.
If water contains a high concentration of minerals, and/or harsh chemical contaminants, and fully dries on a surface it may inflict great harm upon vehicle surfaces.
Water with high mineral contents, combined with sensitive automotive paint, heat, chemicals, or a variety of aggressive natural contamiants, may result in serious paint issues such as deep etching, discoloration, precursors to rust (iron oxide contamination) and even pant failure.
Water spot damage occurs because water acts a transport mechanism, injecting the contamination solids into the porous structure of automotive paint.
Water spot damage may worsen over time if left on the surface. If water spots occur and the vehicle’s paint repeatedly heat cycles (heats up and cools over many days, weeks, or months), the solid contamiants within the water may further chemically react with, and/or attach to, or harm, the paint or surface.
This is why, upon first detection of water spots, it is critical to IMMEDIATELY wash the vehicle.
Immediately washing vehicle surfaces, after detecting water spots, has a high probability of removing most minerals and contamination if they haven’t chemically fuse to or damage surfaces.
Is My Water ‘Hard’ or ‘Soft’? | How to Understand Water Hardness Values with PPM
Ever wondered if your home’s water is ‘hard’ or ‘soft’? This section will explain the concept water hardness levels and classifications.
Understanding water hardness levels allows vehicle owners and detailers to determine if their water is more or less likely to create vehicle water spots on automotive surfaces.
The term “hard” or “soft” water refers to the level of minerals concentrated in water. The most common minerals that harm automotive surfaces are Calcium and Magnesium.
Total Dissolved Solids (TDS) is the term for the amount of minerals contained in a water source. TDS is measured in milligrams per liter (mg/L) or PPM – parts per million.
The higher the PPM value, the greater the amount of total dissolved solids exist within the water.
Often TDS readings are publicly available for reference from local water utility websites. In the US, the Environmental Protection Agency (EPA) requires all water companies to annually test and release a public report on the quality of their water called a ‘drinking water qulity report‘.
If you cannot find a publicly available test, then a simple electronic water tester or water hardness test strip kit will quickly reveal the approximate level of total dissolved solids (minerals) contained in water sources.
The classification scale of ‘soft to hard’ water types are as follows:
- Soft: 0-17mg/L (ppm)
- Slightly Hard: 17.1-60mg/L (ppm)
- Moderately Hard: 61-121mg/L (ppm)
- Hard: 121-180mg/L (ppm)
- Extremely Hard: 180mg/L (ppm) and Higher.
- RIDCULOUSLY HARD: Las Vegas, NV is routinely 270-300 ppm. Some Cities in Arizona and the Rocky Mountains regularly read 450-550 ppm +!
Most metropolitan areas will display municipal water readings between 120-200ppm. If your metropolitan water reads 60ppm or below, then be thankful because you hit the jackpot. Under 100PPM is generally quite safe for automotive surfaces.
In contrast, most rural areas drawing from large or private wells, it is not uncommon to see water at 200-300ppm or higher.
The 4 Critical Vehicle Water Spot Creation Variables
Four critical (key) factors immediately influence how quickly, and to what degree, automotive water spots may form or negatively affect surfaces.
While more variables exist, these four dominant factors give immediate information to help prevent, or troubleshoot, the vast majority of future water spots on automotive surfaces. This knowledge is helpful to all professional auto detailing business, vehicle owners, and enthusiasts to aid in better long-term vehicle care.
Vehicle Water Spot Creation Variable #1: Vehicle Paint Chemical Formulation
The FIRST variable majorly influencing the creation of vehicle water spots is the paint’s chemical makeup.
To understand the vital role a paint’s chemical makeup plays in the creation of water spots, consider the following analogy.
Think of it like spaghetti sauce staining a two vastly different materials. If hot frying oil were to splatter on stainless steel almost nobody would be concerned about damage. This is because the stainless steel is structuraly strong, chemically impervious to the heat, and its immune to staining.
On the other hand, if hot frying oil were to splatter onto a handwoven mulberry silk shirt everyone would worry. Concern about hot oil on mulberry silk is legitimate because the silk is structurally delicate, quite sensitive to heat, and very vulnerable to staining.
This analogy is very similar to how various types of automotive clear coats react to heat and chemical exposure.
Some sensitive automotive paint systems are similar to fine mulberry silk and are quite delicate and vulnerable to most everything including: scratching easily, chemical staining, and low tolerance for heat exposure.
Generally these types paint systems contain weak resins with low chemical resistance and low levels of active solids offering little structural strength. Both of these characteristics create a paint system more vulnerable to the effects of both heat and chemical contamination.
On the other hand, some paint systems have characteristics similar to stainless steel in the analogy. The contain resins with high chemical tolerances and a high solids content offering far greater chemical resistance. These paint systems have proven to be much more resistant to the negative effects of contamination and heat exposure.
Whether a vehicle is more or less prone to the formation of water spot damage, and ultimately damage from waterspots, first depends on its chemical compositon.
Vehicle Water Spot Creation Variable #2: Water’s Mineral & Chemical Makeup and Concentration Levels
The SECOND group of factors influencing the creation of vehicle water spots are the types of minerals contained within water combined with their concentration levels.
The ability to create Damage via Water Spotting or Chemical Damage to paint systems is directly linked to:
- A) The types and combinations of minerals and chemical contaminants contained within the water.
- B) The concentration levels of those minerals, or chemical contaminants, within the water.
Some minerals or chemicals carry a greater likelihood to damage automotive clear coat with minimal quantity like hydroc
Vehicle Water Spot Creation Variable #3: Heat of Surfaces at Time of Water Contact
The THIRD variable of automotive surface water spot creation is HEAT.
More specifically, the temperature of vehicle panels and/or the environment’s ambient temp during water evaporation.
Heat acts as a catalyst to the paint system causing more vulnerability– therefore magnifying the impact of the waters mineral concentration. If a panel is already HOT, say 140°F (~ 60°C) or higher before water contact, that is the worst recipe for quick and deep water spotting.
In direct sun exposure, with atmospheric temperatures between 95°F and 110°F (35-43.5°C) panels can routinely reach surface temperatures of 190-212°F (87-100°C).
In these extreme conditions, the paint is in its most vulnerable condition. This is because heat has swollen the porous paint structure to a fully open state. Therefore, any water contact to these HOT surfaces results in near instant water evaporation. This essentially injects the minerals and chemicals contained within the water directly into the paint’s porous structure.
Even if a car isn’t in direct sunlight, ambient environmental temperatures of 95°F(35C) or higher will still cause paint swell and heighten the chances of water spot creation with water contact.
Therefore, the combination of all three water spot variables of:
- A) a vulnerable paint chemical coposition
- B) corrosive minerals and chemical heavy water
- C) HOT vehicle panels
equals a surefire chemical recipe for disastrous hard water spotting and potential chemical damage.
Some automotive paint systems are so vulnerable to chemical agents that ceramic coating enhancements may only slightly improve the overall chemical protection.
For additional info on heat’s effect on automotive paint systems related to paint correction, Read the OCDCarCare article– Detailing Paint Correction: Paint Swelling & Heat Explained.
Vehicle Water Spot Creation Variable #4: Exposure Time of Water, Minerals, or Chemicals to Surfaces
The FOURTH variable, critical to creation of vehicle surface water spots is TIME.
Particularly, the amount of time the minerals, or contaminants within the water, have been in contact with the surface.
Time allows the chemical composition of some minerals and contamiants to form a more aggressive chemicals bond to automotive paint or surfaces.
When minerals dwell on surfaces for extended periods of time and combine with heat, the results may get ugly– and fast. Generally, the heavier the mineral and contamination content within the water the less time the water may touch automotive surfaces without negative effects.
Depending on the chemical composition of the paint (mentioned above) Time and Heat can greatly influence how aggressive minerals and contamination within water spots may damage paint.
The longer the minerals contained within water spots exist on the paint, and are exposed to heat cycling (heating and cooling), they may further strengthen their bond to surfaces or cause more damage over time.
The main point about time is that, as soon as water spots are noticed on a vehicle they should be removed by a waterless wash or a traditional bucket wash. Quickly washing surfaces after discovering water spots may either fully remove them or greatly minimize their potential to harm surfaces.
Vehicle Water Spot Prevention Strategy
No current paint system or technology, including ceramic coatings and PPF/clear bra, can guarantee complete protection against water spot formation or potential damage.
There is no solve all water spot prevention method for automotive surfaces—No Matter What Certain Coating Manufacturers or Detailing Companies Claim.
It’s just a impossibility within the known physical universe we inhabit– as long as automotive paint remains a thermally dynamic porous structure.
The best ‘prevention’ or protection against vehicle hard water spotting is a STRATEGY.
Water spotting may only be avoided completely, if water is never allowed to dry on a vehicle’s surface. So, yes that is unrealistic in a world where your vehicle is used in a normal daily driver fashion.
Therefore, the best method to avoid the vast majority of water spots, and their potential to damage vehicle surfaces, is to devise a full plan.
Additionally, using mineral free water during car washes (including Waterless and Rinseless wash methods) will ensure vehicle surfaces remain unspotted.
De-ionizing filtration systems remove most, if not all, minerals and deposits from water such as calcium, sodium, iron, copper, and sulfates.
11 Tips to Prevent Water Spots on Automotive Surfaces
1) NEVER Let Water Dry on Automotive Surfaces: Remove Water from Surfaces as Soon as Possible
2) Only Wash Vehicles with Cool Surfaces
3) Avoid Car Washing in Direct Sunlight. Wash Vehicles in Shaded Areas Only
4) After Washing: Immediately Dry Vehicle Surfaces Completely
5) Avoid Parking Near Sprinklers or Any Spraying Water Whenever Possible (such as irrigation)
6) If Incidental Water Contact Occurs, Dry Panel ASAP
7) If a Vehicle is Dirty and Rain Occurs, Wash Vehicle ASAP
8) At home, Purchase a Water Softening System or De-Ionizer for Vehicle Washing
9) For Waterless or Rinseless Car Washing: Mix the Solution using Distilled Water
10) If Washing a Vehicle with Hard Water Use is Unavoidable: Wash Vehicle in Early Morning or Late Evening. Cool Temps, little or no sun.
11) In SUPER HARD Water Regions: Apply a Topical Spray Sealant on Top of a Ceramic Coating for an Extra Layer of Protection
Hard Water Spot Removal Techniques
Upon first detection of water spotting, immediately wash the vehicle to remove the maximum amount of minerals possible from surfaces.
Timing is crucial here and is generally the best and easiest line of defense. Often times, a thorough car wash will remove light or freshly made water spots by cleansing the surfaces and of hard mineral deposits before they set up deep inside the paint system.
Stubborn Water Spot Removal Method After Washing | Acidic Solution
Upon first detection of water spotting, immediately wash vehicle to remove maximum amount of minerals from the affected surfaces.
If washing doesn’t remove water spots, then spot treat areas with an acid-based solution to loosen and remove mineral deposits. Ensure the acid solution is safe for the surfaces containing mineral deposits. Some acid productss are uber aggressive and ruin plastics, rubber, trim, or may even etch glass.
For stubborn or heavier mineral deposit removal, use a dedicated automotive water spot remover. The majority of water spot removers are heavily acidic in nature, so wear full PPE (personal protective equipment) such as: goggles, gloves, and a respirator during use. Also, ONLY apply the product to surfaces indicated as safe on the product label.
NOTE: After any acidic surface treatment, thoroughly flush all panels with water or a waterless wash solution to neutralize the acid.
Household DIY Water Spot Removal Methods | Vinegar & Lemon Juice
For vehicle owners who need to remove a light to medium concentration of water spots and don’t have a dedicated detailing water spot removal product, try distilled white vinegar. The vinegar’s acidity works to chemically break down and loosen light to medium concentrations of common minerals. Once the vinegar has saturated the minerals for 1-2 min, wipe the surface with a soft plush microfiber towel to remove the minerals from the surface.
Apply the vinegar liberally to a microfiber towel and apply evenly to water spots. Allow vinegar to dwell for anywhere from 1-3 min before gently wiping the spots with a soft plush microfiber towel. If spots are stubborn, apply the vinegar a second time and allow the vinegar to dwell 3-6 min before wiping.
If vinegar alone does not work, try mixing in some fresh strained lemon juice with the vinegar in a 50/50 mixture. Apply the lemon/vinegar mixture and allow it to dwell for 2-4 Minutes before wiping the surface with a soft plush microfiber towel.
For a heavier concentration of water spots allow the mixture to dwell for 4-6 min, then liberally apply more vinegar mixture to a microfiber towel before wiping the spots with light to medium pressure.
Removal Method for Etched and Deep Set Hard Water Spots
Topical treatments may not remove some or all hard water spots. If enough minerals, of a strong type, have penetrated far enough into the paint system, or dwelled long enough they may have already etched the paint system.
Paint Polishing (paint correction) may be the only removal method for severe hard water spots on automotive surfaces. Heavy water spots are identified by their: extremely visible heavy mineral deposits, ultra deep position within the paint’s structure, or even by mild to severe surface etching.
Often a light paint correction is enough to remove a large quantity of water spots on automotive paint. However, the more severe and concentrated the spots from heavy mineral concentration within the water– the more aggressive the polishing necessary. For best results, seek out a local reputable detailer to perform such services.
After the removal of hard water spots, make sure to reapply the topical protection that matches the remainder of the vehicle panels.
If water spots are detected immediately after ceramic coating application, the problem is likely a different sort of water spot issue entirely. This removal procedure was explored in a previous OCDCarCare Los Angeles Detailing Article: Phantom Waterspots Appearing After Ceramic Coating Application.
Parting Thoughts on Vehicle Water Spots
To wrap up this examination of vehicle water spots, it must be stated that there is no solution to fully prevent water spots from forming on automotive surfaces.
Well… unless you house the vehicle in a museum.
The best means to avoid vehicle water spots is a full strategy.
A comprehensive water spot prevention strategy includes:
- installing a ceramic coating with high chemical resistance to surfaces
- performing regular washing intervals (once a week or two weeks is best)
- parking your vehicle in a garage out of rain and dew (whenever possible)
- taking quick action to remove any water resting on vehicle surfaces
While it may seem like a lot work to avoid water spots, its mostly just a matter of awareness and maintaining diligence with a regular car washing routine. However, until the chemical composition of automotive paint changes, these are the only proven steps to avoid water spots for daily driven vehicles.
Some automotive ceramic and ‘graphene’ coatings, depending on their chemical composition, offer the best modern protection for vehicle surfaces against water spot creation or damage. A ceramic coating’s protection against water spots is provided by the coating’s combined chemical protection capabilities and its ability to shed water off a surface, which is one aspect of its hydrophobic properties.
While ceramic coatings are a great line of defense, they can’t prevent water spots because coatings only work with automotive paint’s characteristics. They cannot replace the chemistry and physical characteristics of the vehicle paint systems and surfaces they bond to.
If ceramic coatings were to replace the physical characteristics of modern paint, acting like a spackle–as some coating manufacturers suggest and/or advertise–then these formulas would inhibit the paint’s ability to expand and contract according to heat exposure. If automotive paint could not swell and shrink with paint, according to heat demands, it would fracture, fail, and eventually delaminate from the surface.
If vehicle owners follow the 11 water spot prevention tips listed previously in this article, then your vehicle and your blood pressure will thank you, as you will avoid most common water spots issues over time.
